The QH-420/520 electronic weighing packaging machine is composed of the host machine, ten-head weigher, support platform for the electronic weigher, Z-type material hoist, and conveyor. It is suitable for the packaging requiring high measurement accuracy or for packaging of friable bulk materials, such as herb, jelly, candy, chocolate, dumpling, pistachio, pet food, puffed food, crispy rice, shrimp chips, glue pudding, hardware part, etc.

Specifications

Max. Width of the Film	420mm	520mm
Bag Length	80-300mm	80-350mm
Bag Width	50-200mm	80-250mm
Packaging Speed	50-60bag/min	10-50bag/min
Measuring Range	150-1200ml	2000ml
Air Pressure	0.65Mpa	0.65Mpa
Gas Consumption	0.3m3/min	0.3m3/min
Voltage	220V/2.2kw	220V/4kw
Dimensions	(L)1320×(W)950× (H)1360mm	(L)1750×(W)1150× (H)1800mm
Weight	540kg	800kg

Controlled by PLC, this equipment runs more stably. Ten sets of parameters can be stored and each parameter can be adjusted without halt. The servo motor is adopted to pull the film, so the positioning is more accurate. Temperature of the transverse and longitudinal sealing is controlled independently and the precision can reach ±1℃.

There are diverse packing forms, such as back sealing, end inserting, bag linking, punching, etc. Bag-making, sealing, packing, and date printing are finished successively and smoothly. In addition, our electronic weighing packaging machine is easy to operate and it produces little noise.

Ten-head Weigher
The high-precision digital weighing sensor enables the measurement to be realized instantaneously. After the calculation of the computer, the optimal combination of objects is selected from the abundant weight combinations. According to the characteristics of the object under measurement, the ten-head weigher can record several indicators of the first batch of products, such as the total number of packets, qualified rate, single bag error, etc.

Made of stainless steel, this equipment has a protection grade of IP65 and is thus clean and sanitary. The fully sealed design prevents accumulation of materials and facilitates cleaning. The multilingual LCD operating system makes it easy to operate. There are several optional devices, including collection hopper, printing device, hopper with decorative patterns, and error-exceeding sorting device.

Specifications

Item	Parameter
Number of the Measuring Head	10
Range of Single Measurement	10-1000g
Accuracy	0.1-1.5g
Weighing Speed	70bag/min
Hopper Capacity	1300ml
Hopper Type	Double-row Non-memory Hopper
Preset Mode	99
Net Weight/Gross Weight	300/370kg
Size of the Outer Packing	(L)1400*(W)1130*(H)1120

As a professional electronic weighing packaging machine manufacturer and supplier in China, we also offer mooncake production line, chocolate pouring production line, far infrared tunnel electric oven, hard candy production line, and much more.
